GENERAL SPECIFICATIONS
OVERALL LENGTH - 8.15m / 26ft’ 9in”
BEAM - 2.70m / 8ft’ 10.3 in”
CHINE BEAM - 2.52m / 8ft 3.2"
TOTAL HEIGHT - 2.68m / 8ft' 9.5 in"
DRAFT - 480mm / 1ft' 6.8 in” (Fully Laden)
ALUMINIUM WEIGHT - 1,621kg
LIGHTSHIP DISPLACEMENT - 2,167kg
DESIGN DISPLACEMENT - 3,614kg
FUEL VOLUME - 530L
FRESH WATER VOLUME - NIL
DESIGN POWER - 300HP
LEG LENGTH - 25"
TRANSOM RAKE - 15°
ABP MAX POWER RATING - 300HP
ABP MAX PERSONS - 8
ABP MAX LOAD - 1,056KG (Person + Engine + Cargo)
ABP FLOTATION - BASIC (Optional)
ABP - FOAM REQUIRED - 1.88m³
